With a real-time self-diagnosis monitoring system, it can immediately diagnose itself in the event of a malfunction, displaying an error code. Additionally, with Auto protection technology, our ACs can initiate emergency power downs when close to a system overload.
Package, Dimension & Weight
Packing Dimensions (WxDxH) |
480x880x380
|
Condenser Outdoor coil
Fin type (code) COC |
hydrophilic aluminium
|
Evaporator Indoor coil
Fin type (code) EIC |
hydrophilic aluminium
|
Oven Accessories
Net Weight (kg) |
27
|
Gross Weight (kg) |
32
|
Dimensions
Net Dimensions – WxHxD (mm) |
430x695x325
|
Packing Dimensions (WxDxH) |
480x880x380
|
Net Weight (kg) |
27
|
Gross Weight (kg) |
32
|
Approvals |
CB
|
Filter information
Washable PP filter |
Yes
|
HEPA Filter |
No
|
Removable Filter |
Yes
|
Stack Limit |
3
|
Features
Display on Front Panel |
LED
|
24 Hours Timer |
Yes
|
Timer ON/OFF |
Yes
|
Sleep function |
Yes
|
Auto Restart |
Yes
|
Dehumidification function |
Yes
|
Unit Control Type |
Electronic
|
Fan Control |
Button
|
Thermostat Control |
Button
|
Dry Mode (auto speed only) |
Yes
|
Water Full Indicator |
Yes
|
Auto Cool (auto fan in cooling) |
Yes (on the controller)
|
Smart Mode (remote access) |
Yes (on the controller)
|
Rapid Cool (Jet) Mode – Remote only |
Yes (on the controller)
|
Fan Only |
Yes – 3 Speed
|
Anion |
No
|
Cooling Speed Selections |
3
|
Clock |
Yes (on the controller)
|
Air Swing (Motorized – Up & Down) |
Yes
|
Room Temperature Display Units (F or C) factory default |
Yes
|
Fahrenheit to Celsius function |
Yes
|
Vent System |
Single Duct
|
System
Compressor Model No. |
ASN93V11UDZ1
|
Compressor MFG |
GMCC
|
Expansion Device |
Flow restrictor
|
Evaporator |
Copper tube and Aluminum Fin
|
Condenser |
Copper tube and Aluminum Fin
|
Power Supply
Voltage |
220-240V
|
Frequency |
50Hz
|
Phase |
1P
|
Rated Current Cooling (A) |
5
|
Rated Current Heating (A) |
4.7
|
LRA |
19.2
|
Ratings
Cooling Capacity |
3100
|
Heating Capacity |
2640
|
Power Input-Cooling |
1000
|
Power Input-Heating |
942
|
Air Circulation |
290
|
EER |
3.1
|
COP |
2.8
|
Refrigerant |
R410A
|
Refrigerant volumn |
490
|
Unit Noise Level |
52
|
Specs
More
Loading Capacity (40′ HC) |
447
|
