With a real-time self-diagnosis monitoring system, it can immediately diagnose itself in the event of a malfunction, displaying an error code. Additionally, with Auto protection technology, our ACs can initiate emergency power downs when close to a system overload.
Package, Dimension & Weight
| Packing Dimensions (WxDxH) |
480x880x380
|
Condenser Outdoor coil
| Fin type (code) COC |
hydrophilic aluminium
|
Evaporator Indoor coil
| Fin type (code) EIC |
hydrophilic aluminium
|
Oven Accessories
| Net Weight (kg) |
27
|
| Gross Weight (kg) |
32
|
Dimensions
| Net Dimensions – WxHxD (mm) |
430x695x325
|
| Packing Dimensions (WxDxH) |
480x880x380
|
| Net Weight (kg) |
27
|
| Gross Weight (kg) |
32
|
| Approvals |
CB
|
Filter information
| Washable PP filter |
Yes
|
| HEPA Filter |
No
|
| Removable Filter |
Yes
|
| Stack Limit |
3
|
Features
| Display on Front Panel |
LED
|
| 24 Hours Timer |
Yes
|
| Timer ON/OFF |
Yes
|
| Sleep function |
Yes
|
| Auto Restart |
Yes
|
| Dehumidification function |
Yes
|
| Unit Control Type |
Electronic
|
| Fan Control |
Button
|
| Thermostat Control |
Button
|
| Dry Mode (auto speed only) |
Yes
|
| Water Full Indicator |
Yes
|
| Auto Cool (auto fan in cooling) |
Yes (on the controller)
|
| Smart Mode (remote access) |
Yes (on the controller)
|
| Rapid Cool (Jet) Mode – Remote only |
Yes (on the controller)
|
| Fan Only |
Yes – 3 Speed
|
| Anion |
No
|
| Cooling Speed Selections |
3
|
| Clock |
Yes (on the controller)
|
| Air Swing (Motorized – Up & Down) |
Yes
|
| Room Temperature Display Units (F or C) factory default |
Yes
|
| Fahrenheit to Celsius function |
Yes
|
| Vent System |
Single Duct
|
System
| Compressor Model No. |
ASN93V11UDZ1
|
| Compressor MFG |
GMCC
|
| Expansion Device |
Flow restrictor
|
| Evaporator |
Copper tube and Aluminum Fin
|
| Condenser |
Copper tube and Aluminum Fin
|
Power Supply
| Voltage |
220-240V
|
| Frequency |
50Hz
|
| Phase |
1P
|
| Rated Current Cooling (A) |
5
|
| Rated Current Heating (A) |
4.7
|
| LRA |
19.2
|
Ratings
| Cooling Capacity |
3100
|
| Heating Capacity |
2640
|
| Power Input-Cooling |
1000
|
| Power Input-Heating |
942
|
| Air Circulation |
290
|
| EER |
3.1
|
| COP |
2.8
|
| Refrigerant |
R410A
|
| Refrigerant volumn |
490
|
| Unit Noise Level |
52
|
Specs
More
| Loading Capacity (40′ HC) |
447
|
